Horizontal Steam Sterilizer

Product Introduction:

The VEC-DGS-K vertical electric heating autoclave adopts full stainless steel construction and microcomputer digital control. It supports adjustable sterilization temperature and time, and integrates comprehensive safety protections including over-temperature, over-pressure and low-water cut-off functions. Fitted with a self-inflating seal and automatic steam exhaust, this compact vertical sterilizer delivers stable daily disinfection for culture media, lab glassware and medical tools, widely used in labs, clinics and research institutes.

Features

· Horizontal circular inner chamber with double-layer structure, featuring high safety, excellent thermal insulation and drying performance

· High-quality stainless steel pipes with clamp-type quick-installation design, optimized layout, facilitating maintenance and cleaning

· Built-in steam generator, energy-saving and highly efficient

· Adopting pneumatic sealing, which offers excellent sealing performance and convenient operation

· Equipped with a standard equipment verification interface, making verification work easy to carry out

· Adopting HMI (Human-Machine Interface) with touch screen + microcomputer control system

· The sterilization effect is double guaranteed by F₀ value and temperature/time

· Equipped with a complete sterilization data recording function to ensure the whole process is traceable

· Capable of realizing functions such as program selection, parameter setting, equipment operation and report processing.

· Equipped with multiple safety protection measures to ensure safe and reliable operation of the equipment

· Supported sterilization processes: fabric sterilization, instrument sterilization, liquid sterilization, BD test, pressure holding test, and multiple customizable programs can be set

Applications

The horizontal steam sterilizer uses saturated steam as the sterilizing medium. Taking advantage of the high latent heat released during steamondensation and the strong penetrability of steam, it achieves effective sterilzation through a period of heat preservation. Itis suitable forsterilizing and drying medical textiles, surgical instruments, utensils, culture media, and glassware.The system features a fuly automatic control with a user-friendy interface, incuding automatic temperature recording and vacuum dringfunctions. Itis widely used in hospital CSsDs and operating rooms, as well as in pharmaceutical factories ,laboratories, and research institutionsfor disinfection and sterilization purposes.

TECHNICAL PARAMETERS

Models & Technical Parameters (Gravity displacement)

Model	Volume (L)	Overall Dimensions (LxWxH)(mm)	Chamber Dimensions (LxWxH)(mm)	Steam Consumption (kg)	Water Consumption (kg)	Power (KW)	Gross Weight (kg)	Net Weight (kg)
VECT-150WY	150	1260x690x1740	φ472x880	≤13	≤30	≤18	470	390
VECT-150SWY	150	1130x690x1740	φ472x880	≤13	≤30	≤18	540	460
VECT-200WY	200	1490x690x1740	φ472x1150	≤15	≤35	≤23	535	435
VECT-200SWY	200	1360x690x1740	φ472x1150	≤15	≤35	≤23	605	505
VECT-300WY	300	1400x850x1760	φ620x995	≤20	≤40	≤23	645	540
VECT-300SWY	300	1145x850x1760	φ620x995	≤20	≤40	≤23	705	610
VECT-400WY	400	1680x850x1760	φ620x1320	≤25	≤45	≤23	740	630
VECT-400SWY	400	1495x850x1760	φ620x1320	≤25	≤45	≤23	820	710

Models & Technical Parameters (Pulsation Vacuum)

Model	Volume (L)	Overall Dimensions (LxWxH)(mm)	Chamber Dimensions (LxWxH)(mm)	Steam Consumption (kg)	Water Consumption (kg)	Power (KW)	Gross Weight (kg)	Net Weight (kg)
VECT-WY-150D	150	1260x690x1740	φ472x880	≤13	≤30	≤18	470	390
VECT-WY-150S	150	1130x690x1740	φ472x880	≤13	≤30	≤18	540	460
VECT-WY-200D	200	1490x690x1740	φ472x1150	≤15	≤35	≤23	535	435
VECT-WY-200S	200	1360x690x1740	φ472x1150	≤15	≤35	≤23	605	505
VECT-WY-300D	300	1400x850x1760	φ620x995	≤20	≤40	≤23	645	540
VECT-WY-300S	300	1145x850x1760	φ620x995	≤20	≤40	≤23	705	610
VECT-WY-400D	400	1680x850x1760	φ620x1320	≤25	≤45	≤23	740	630
VECT-WY-400S	400	1495x850x1760	φ620x1320	≤25	≤45	≤23	820	710
