Pneumatic liposome extruders are designed for particle size standardization, impurity removal, and particle size reduction of liposomes and emulsions to support sterile filtration. They are also widely applied in molecular kinetics studies and pharmaceutical formulation research.
Regulatory & Sanitary Compliance
All sealing components of the Pneumatic Liposome Extruder comply with FDA standards.The full-channel design features dead-angle-free sanitation, ensuring GMP compliance and biocompatibility for pharmaceutical use.
Safe & Efficient Operation
Equipped with a safety relief valve for secure high-pressure operation. Tool-free membrane replacement and quick disassembly enable efficient cleaning, sterilization, and workflow.
Premium Material & Durability
All product-contact parts and pipelines are constructed from 316L stainless steel. Reusable PC filter membranes ensure cost-effectiveness, corrosion resistance, and consistent performance.
High Compatibility & Zero Residue
Supports high-viscosity product processing with minimal material residue (<0.5mL), ideal for expensive raw materials. It delivers uniform nanoscale particles (50-1000nm) via precise pressure control.
Preparation of liposomes and lipid nanoparticles (LNPs)
Development of liposomal drug delivery systems
Research on nanomedicine, gene delivery, and vaccine formulations
Particle size homogenization and nanosizing of lipid vesicles
Small-scale formulation trials in pharmaceutical R&D and laboratory studies
Model | LE-15 |
Processing Mode | Batch Processing |
Standard Processing Volume | 0.5~15 mL/batch |
Final Sample Particle Size | 50-1000 nm (dependent on filter membrane) |
Maximum Sample Concentration | 200 mg/mL |
Operating Temperature Range | 5-75°C |
Maximum Extrusion Pressure | 1000 psi |
Safety Relief Pressure | 1000 psi |
Available Filter Membrane Diameter | 25 mm |
Temperature Control Method | Jacket Temperature Control |
Polycarbonate Membrane Pore Sizes (Optional) | 50 nm, 100 nm, 200 nm, etc. |
Standard Membrane Pore Size | 100 nm |
Equipment Material | AISI 316L Stainless Steel |
Sealing Components | All seals meet FDA standards |
Modular Design | Fully GMP-compliant |
Cleaning & Sterilization | Autoclavable & Sterilizable by High Pressure Steam |
Optional Configuration | Filter membranes with various pore sizes |
Pneumatic liposome extruders are engineered for precise particle size reduction, uniform particle size standardization and fine impurity removal of liposomes and nanoemulsions, enabling reliable downstream sterile filtration.
Pneumatic liposome extruders are engineered for precise particle size reduction, uniform particle size standardization and fine impurity removal of liposomes and nanoemulsions, enabling reliable downstream sterile filtration.
Pneumatic liposome extruders are designed for particle size standardization, impurity removal, and particle size reduction of liposomes and emulsions to support sterile filtration.
