4.3-inch high-definition wide-angle IPS capacitive color LCD display for intuitive operation
Combined touchscreen and physical key operation, delivering excellent user experience
External control signals support wide 5–24V voltage input
Standard functions: forward/reverse rotation, start/stop, full-speed operation and suck-back
Reliable embedded software system, convenient for product customization and upgrade
Four operating modes: Flow Mode, Time Dispensing, Volume Dispensing, Programmable Mode
Up to 5 sets of dispensing parameters can be pre-stored for volume and time dispensing
4.3-inch high-definition wide-angle IPS capacitive color LCD display for intuitive operation
Combined touchscreen and physical key operation, delivering excellent user experience
External control signals support wide 5–24V voltage input
Standard functions: forward/reverse rotation, start/stop, full-speed operation and suck-back
Reliable embedded software system, convenient for product customization and upgrade
Four operating modes: Flow Mode, Time Dispensing, Volume Dispensing, Programmable Mode
Up to 5 sets of dispensing parameters can be pre-stored for volume and time dispensing
Wizard-guided flow calibration function, simple and user-friendly
Graphical tubing selection for pump heads, clear and straightforward
Flow Mode supports delayed start and timed stop
Unique suck-back function to effectively prevent liquid dripping
Programmable Mode supports parameter setting for up to 30 segments to realize complex control procedures
Intelligent temperature control; automatically adjusts heat dissipation according to ambient conditions to maintain optimal equipment status
External analog speed regulation; external signals control start/stop, direction and dispensing with galvanic isolation
RS485 communication with MODBUS protocol; communication parameters configurable for connection with various control devices
Multiple accessible control parameters available, suitable for OEM customized applications
Circuit board coated with three-proof paint for dustproof and moisture-proof performance
Outstanding anti-interference performance and wide voltage design, adaptable to complex power supply environments
Innovative stainless steel housing, easy to clean and resistant to erosion by various organic solvents
Application Fields
Modern laboratories
Industrial production
Agriculture
Chemical industry
Biopharmaceuticals
Typical Applications
TFF & DFF ultrafiltration
Fluidized bed processing
Additive dosing
Tubular centrifuge supporting
Material dispensing for pharmaceutical factories
Parameter | Specification |
Flow Rate Range | 0.0013 ~ 13.2 L/min |
Speed Range | 0.1 ~ 600.0 rpm |
Speed Resolution | 0.1 rpm |
Speed Accuracy Error | < ±0.2% |
External Control Signal Input (Start/Stop) | Dry contact, external control input level (5~24V) |
External Control Signal Input (Forward/Reverse) | Dry contact, external control input level (5~24V) |
External Control Signal Input (Speed Regulation) | Analog 0~5V, 0~10V, 4~20mA configurable |
Power Supply Voltage | AC 100-240V 50/60Hz |
Power | < 400W |
Operating Environment | Temperature 0~40°C, relative humidity < 80% |
Dimensions (L × W × H) | 333 × 233 × 269 mm |
Protection Rating | IP31 |
External Control Signal Output (Speed Status) | Analog 0~5V |
External Digital Communication | RS485 communication, compatible with Modbus protocol, DB15 interface, WiFi optional |
Drive Weight | 10.2 kg |
Dispensing Volume Setting Range | 0.001μL ~ 999.0L (min. recommended filling: 100mL) |
Dispensing Count Setting Range | 1 ~ 50,000 cycles; "0" for infinite loop |
Dispensing Interval Setting | 0.1 ~ 999.9 sec/min/hr, time unit adjustable |
